A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 2 SOLID COPPER DATA CABLING • 24AWG Solid Copper Conductors • UTP Unscreened • Also stocked in a range of colours • Other lengths also available • Direct Burial & SWA types from stock CATEGORY 5E UTP UNSCREENED SOLID COPPER DATA CABLING Category 5E Code 305m, 4pr UTP Grey PVC SFX/C5-UTP-PVCGRY-305 305m 4pr UTP Purple LSZH SFX/C5-UTP-LSZHPUR-305 305m 4pr UTP Black PE SFX/C5-UTP-PEBLK-305 100m 4pr UTP SWA Black PE SFX/C5-UTP-SWA-PEBLK-100 Category 6 Code 305m 4pr UTP Grey PVC SFX/C6-UTP-PVCGRY-305 305m 4pr UTP Purple LSZH SFX/C6-UTP-LSZHPUR-305 305m 4pr UTP Black PE SFX/C6-UTP-PEBLK-305 100m 4pr UTP SWA Black PE SFX/C6-UTP-SWA-PEBLK-100 CATEGORY 6 UTP UNSCREENED SOLID COPPER DATA CABLING • 24AWG Solid Copper Conductors • UTP Unscreened • Also stocked in a range of colours • Other lengths also available • Direct Burial & SWA types from stock ENHANCED CATEGORY 6A DATA CABLING Category 6A Code 305m 4pr F/ FTP Blue LSZH SFX/C6A-F-FTP-LSZHBLU-305 305m 4pr U/FTP Blue LSZH SFX/C6A-UFTP-LSZHBLU-305 4pr F/FTP Black PE /m SFX/C6A-F-FTP-PEBLK-1 • 500MHz Solid Copper Data Cable • Screened as standard • Cut lengths available in 50m increments • Also stocked in Yellow & White LSZH CATEGORY 5E FTP SCREENED SOLID COPPER DATA CABLING Category 5E Code 305m 4pr FTP Grey PVC SFX/C5-FTP-PVCGRY-305 305m 4pr FTP Purple LSZH SFX/C5-FTP-LSZHPUR-305 305m 4pr FTP Black PE SFX/C5-FTP-PEBLK-305 100m 4pr FTP SWA Black PE SFX/C5-FTP-SWA-PEBLK-100 • 24AWG Solid Copper Conductors • FTP Screened • Other lengths also available • Screened RJ45 Connectors available from stock CATEGORY 6 FTP SCREENED SOLID COPPER DATA CABLING Category 6 Code 305m 4pr FTP Purple LSZH SFX/C6-FTP-LSZHPUR-305 305m 4pr FTP Black PE SFX/C6-FTP-PEBLK-305 • 23AWG Solid Copper Conductors • FTP Screened • Other lengths also available • Screened RJ45 Connectors available from stock ENHANCED CAT 7A & CAT 8 DATA CABLING Category 7A /m Code 4pr S/FTP Orange LSZH SFX/C7A-S-FTP-LSZHORG-1 4pr S/FTP Black PE SFX/C7A-S-FTP-PEBLK-1 Category 8.1 100m 4pr S/FTP Green LSZH SFX/C8.1-S-FTP-LSZHGRN-100 • Enhanced Solid Copper Data Cable • S/FTP Screened as standard • Cut lengths available in 50m increments1000Mhz (Cat7A) or 2000MHz (Cat8) SFX100 PREMIUM COAXIAL CABLE LSZH Coaxial Premium Code 100m Black SFX/100-LSZH-DBLK-100 250m Black SFX/100-LSZH-DBLK-250 100m Twin Black SFX/100-TWIN-LSZHBLK-100 250m Twin Black SFX/100-TWIN-LSZHBLK-250 100m 5 Core + 4mm E Black SFX/100X5-LSZHBLK-100 SFX100 PREMIUM COAXIAL CABLE PVC SFX100 PREMIUM COAXIAL CABLE LSZH SFX100 PREMIUM COAXIAL CABLE CAI APPROVED RANGE PVC Coaxial Premium Code 100m Black SFX/100-PREM-PVCBLK-100 250m Black SFX/100-PREM-PVCBLK-250 100m Twin Black SFX/100-TWIN-PVCBLK-100 250m Twin Black SFX/100-TWIN-PVCBLK-250 • Solid Copper Conductor • Foam-Filled Dielectric • Foil & Braid Screening • Also stocked in White • Other lengths available Coaxial Premium Code 100m Black PVC SFX/100-CAI-PVCBLK-100 250m Black PVC SFX/100-CAI-PVCBLK-250 100m Black LSZH SFX/100-CAI-LSZHBLK-100 250m Black LSZH SFX/100-CAI-LSZHBLK-250 100m Twin Black LSZH SFX/100-CAI-TWINLSZH-BLK-100 250m Twin Black LSZH SFX/100-CAI-TWINLSZH-BLK-250 CAI Platinum Approved www.securiflex.co.uk
3 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 RG6 Coaxial Code SFX125 Coaxial Black PE /m SFX/125-PE-BLK-1 SFX165 Coaxial Black PE /m SFX/165-PE-BLK-1 SFX125 Coaxial Direct Burial Green PE SFX/125-DB-GRN-1 RG59 Coaxial SWA CCA Black PE /m SFX/59-SWA-PE-BLK-1 RG11 Coaxial 7/0.40 Black LSZH /m SFX/RG11-LSZH-BLK-1 100m RG59 Mini Coaxial 1/0.41m White LSF SFX/59-MINI-LSFWHT-100 RG6 COAXIAL CABLES ADDITIONAL COAXIAL CABLE TYPES • CCS Conductor • Foam-Filled Dielectric • Foil & Braid Screening • Also stocked in White/Brown RG6 Coaxial Code 100m Black PVC SFX/RG6-PVC-BLK-100 250m Black PVC SFX/RG6-PVC-BLK-250 100m Twin Black PVC SFX/RG6-TWIN-PVCBLK-100 250m Twin Black PVC SFX/RG6-TWIN-PVCBLK-250 • Cut to length cables sold in 50m increments • Many other types available • Please enquire with any specific requirements 100m RG59 Coaxial Code CCA Black PVC SFX/59-PVC-BLK-100 CCA Black LSF SFX/59-LSF-BLK-100 CCA Black PE SFX/59-PE-BLK-100 + 2 Power Cores 0.5mm CCA Black PVC SFX/59+2C-0.5-PVCBLK-100 + 2 Power Cores 0.75mm Black LSF SFX/59+2C-0.75-LSFBLK-100 + 2 Power Cores 0.5mm CCA Black PE SFX/59+2C-0.5-PEBLK-100 RG59 COAXIAL CABLES • CCA Conductor • Premium Range also available • Foil & Braid Screening • Also stocked in White; Other lengths available • SWA types from stock TELECOM & SPEAKER CABLES Speaker Cable Code Description 2 Core OFC 1.5mm Parallel Gold Clear PVC SFX/SPK-SS-2C-PL-1.5-PVC-CLR-100 2 Core OFC 2.5mm Parallel Gold Clear PVC SFX/SPK-SS-2C-PL-2.5-PVC-CLR-100 2 Core OFC 2.5mm Round Black LSZH SFX/SPK-SS-2C-2.5-LSZH-BLK-1 2 Core OFC 4.0mm Round Black LSZH SFX/SPK-SS-2C-4.0-LSZH-BLK-1 4 Core OFC 2.5mm Round Black LSZH SFX/SPK-SS-4C-2.5-LSZH-BLK-1 CW1308 TELEPHONE CABLES LSF BUDGET RANGE TELEPHONE CABLES PVC EXTERNAL GRADE TELECOM CABLES PE BLACK BUDGET RANGE SPEAKER CABLES PVC PREMIUM OFC SPEAKER CABLE RANGE ADDITIONAL SPEAKER CABLE TYPES • Copper Conductors • White LSF Sheath • Other lengths available 100m CW1308 Code 2 Pair White LSF SFX/CW1308-2-LSFWHT-100 3 Pair White LSF SFX/CW1308-3-LSFWHT-100 4 Pair White LSF SFX/CW1308-4-LSFWHT-100 6 Pair White LSF SFX/CW1308-6-LSFWHT-100 10 Pair White LSF SFX/CW1308-10-LSFWHT-100 20 Pair White LSF SFX/CW1308-20-LSFWHT-100 • CCS Conductors • White PVC Sheath • Supplied on 100m reels Budget Telecom Cable Code 2pr CCS White PVC SFX/TC-2-PVC-WHT-100 3pr CCS White PVC SFX/TC-3-PVC-WHT-100 4pr CCS White PVC SFX/TC-4-PVC-WHT-100 6pr CCS White PVC SFX/TC-6-PVC-WHT-100 • Copper Conductors • Suitable for external use • Cut to length in 50m increments • Petroleum Jelly filled CW1128 Code Description 5pr 0.5mm PJ Filled Black PE SFX/CW1128-5-PEBLK-U-1 10pr 0.5mm PJ Filled Black PE SFX/CW1128-10-PEBLK-U-1 5pr 0.5mm PJ Filled SWA Black PE SFX/CW1198-5-SWAPE-BLK-U-1 10pr 0.5mm PJ Filled SWA Black PE SFX/CW1198-10-SWAPE-BLK-U-1 • CCA Conductors • White PVC Sheath • Black tracer line • Supplied on 100m reels Speaker Cable PVC Code 2 Core 13 Strand (0.4mm) White SFX/SPK-13-PVCWHT- 100 2 Core 42 Strand (1.5mm) White SFX/SPK-42-PVCWHT- 100 2 Core 79 Strand (2.5mm) White SFX/SPK-79-PVCWHT- 100 • Oxygen Free Copper • Other lengths Available • Cut in 50m increments • Distinctive Sheath Colours Speaker Cable Code 100m 2 Core 16AWG Pink LSZH SFX/SPK-PRO-2CLSZH-PNK-100 100m 2 Core 16AWG Black PE SFX/SPK-PRO-2C-PEBLK-100 100m Cable 4 Core 16AWG Pink LSZH SFX/SPK-PRO-4CLSZH-PNK-100 100m 4 Core 16AWG Black PE SFX/SPK-PRO-4C-PEBLK-100 2 Core 14AWG Purple LSZH SFX/SPK-PRO-2C-14-LSZH-PUR-1 4 Core 14AWG Purple LSZH SFX/SPK-PRO-4C-14-LSZH-PUR-1 • Oxygen Free Copper • Other lengths Available • Cut in 50m increments • Highly Stranded & Flexible SATELLITE & CCTV COAXIAL CABLES
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 4 Securi-Flex have a comprehensive range of Belden Equivalent cables available from stock, in addition to those listed. Please contact your wholesaler with any specific requirements you may have. www.securiflex.co.uk Description Codes 1pr 14AWG Grey LSZH (8473) SFX/USC2-14-LSZH-GRY 1pr 20AWG Grey LSZH (8205) SFX/USC2-20-LSZH-GRY 1pr 16AWG Grey LSF (8471) SFX/USP1-16-LSZH-GRY 1pr 18AWG Grey LSZH (9740) SFX/USP1-18-LSZH-GRY 1pr 18AWG M-Bus Pink LSZH (9740) SFX/USP1-18-MBUSLSZH-PNK 1pr 18AWG E-Bus Blue LSZH (9740) SFX/USP1-18-EBUSLSZH-BLU BELDEN EQUIVALENT CABLES BELDEN STYLE: INDIVIDUALLY SCREENED PAIRS • Copper Conductors 600V Rated • Individually Foil Screened • LSF, LSZH, PE & SWA Sheath Options Available • Cut to Length • 24AWG, 22AWG, 20AWG & 18AWG Options Available • Dca CPR Rated Options Available Description Code 2pr Grey 22AWG LSF (8723) SFX/ISP2-LSF-GRY 2pr Grey 22AWG LSZH (8723) SFX/ISP2-LSZHGRY 2pr 22AWG Black PE (8723) SFX/ISP2-PE-BLK 3pr 22AWG Grey LSF (8777) SFX/ISP3-LSZHGRY 6pr 22AWG Grey LSZH (8778) SFX/ISP6-LSZH-GRY 2pr 18AWG LSZH (9368) SFX/ISP2-18-LSZHGRY 2pr 20AWG Grey LSZH (9402) SFX/ISP2-20-LSZHGRY 3pr 18AWG Grey LSZH (9773) SFX/ISP3-18-LSZHGRY BELDEN STYLE: OVERALL SCREENED CORES & PAIRS • Copper Conductors 600V Rated • Overall Foil Screened • LSF, LSZH, PE & SWA Sheath Options Available • Cut to Length • 24AWG, 22AWG, 20AWG, 18AWG, 16AWG & 14AWG Options Available • Dca CPR Rated Options Available Description Code 4 Core 24AWG Grey LSF (9534) SFX/OSC4-LSZH-GRY 6 Core 24AWG Grey LSF (9536) SFX/OSC6-LSZH-GRY 8 Core 24AWG Grey LSF (9538) SFX/OSC8-LSZH-GRY 10 Core 24AWG Grey LSZH (9540) SFX/OSC10-LSZH-GRY 10 Core 24AWG Black PE (9540) SFX/OSC10-PE-BLK 1pr 24AWG Grey LSF (9501) SFX/OSP1-LSZH-GRY 2pr 24AWG Grey LSF (9502) SFX/OSP2-LSZH-GRY 3pr 24AWG Grey LSF (9503) SFX/OSP3-LSZH-GRY 4pr 24AWG Grey LSF (9504) SFX/OSP4-LSZH-GRY 6pr 24AWG Grey LSF (9506) SFX/OSP6-LSZH-GRY 1pr 18AWG Grey LSF (8760) SFX/OSP1-60-LSZH-GRY 1pr 22AWG Grey LSF (8761) SFX/OSP1-61-LSZH-GRY 1pr 20AWG Grey LSF (8762) SFX/OSP1-62-LSZH-GRY 1pr 16AWG Grey LSZH (8719) SFX/OSP1-19-LSZH-GRY OVERALL FOIL AND BRAID SCREEN 1pr 24AWG Grey LSF (9841) SFX/OFB1-LSZH-GRY 2pr 24AWG Grey LSZH (9842) SFX/OFB2-LSZH-GRY BELDEN STYLE: UNSCREENED • Copper Conductors 600V Rated • Unscreened • LSZH Sheath • Cut to Length • 24AWG, 22AWG, 20AWG, 18AWG, 16AWG & 14AWG Options Available • Dca CPR Rated Options Available Part Codes Sizes Description SFX/2182Y- ‘Colour’ Available Sizes (mm) 0.5 & 0.75 2 Core PVC SFX/2192Y- ‘Colour’ Available Sizes (mm) 0.5 & 0.75 2 Core PVC SFX/3182Y- ‘Colour’ Available Sizes (mm) 0.75, 1 & 1.5 2 Core PVC SFX/3183Y- ‘Colour Available Sizes (mm) 0.75, 1 & 1.5 3 Core PVC SFX/3184Y- ‘Colour’ Available Sizes (mm) 0.75, 1 & 1.5 3 Core PVC SFX/3182B- ‘Colour’ Available Sizes (mm) 0.75, 1, 1.5 & 2.5 2 Core LSZH SFX/3183B- ‘Colour’ Available Sizes (mm) 0.75, 1, 1.5 & 2.5 3 Core LSZH SFX/3184B- ‘Colour’ Available Sizes (mm) 0.75, 1, 1.5 & 2.5 4 Core LSZH SFX/3185B- ‘Colour’ Available Sizes (mm) 0.75, 1, 1.5 & 2.5 5 Core LSZH SFX/3186B- ‘Colour’ Available Sizes (mm) 0.75, 1, 1.5 & 2.5 6 Core LSZH SFX/3187B- ‘Colour’ Available Sizes (mm) 0.75, 1, 1.5 & 2.5 7 Core LSZH FLEXIBLE WIRING & CONTROL CABLES • Available in Black & White • PVC & LSZH Sheath Options Available A wide range of CY’s, SY’s & YY’s are also available from stock
5 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 by CABINETS & CONNECTIVITY NEW FOR 2024! Wall Cabinets Cabinet Accessories Connectivity Equipment Tools Contact your local Wholesaler for more information!
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 6 ventcroft.co.uk NOBURN Platinum: Fire Cable Standard 60 Key Lines / 100m Reel Red Sheath White Sheath Size Cores VFP-215ERD VFP-215EWT 1.5 mm2 2 Core & CPC VFP-315ERD VFP-315EWT 1.5 mm2 3 Core & CPC VFP-415ERD VFP-415EWT 1.5 mm2 4 Core & CPC VFP-225ERD VFP-225EWT 2.5 mm2 2 Core & CPC 200m and 500m reels available BS 7629-1 Standard 60 BS 5839-1 26.2d Colour: Red, White, Black, Orange NOBURN® Platinum Fire Performance Cables BS 8436 Life Safety NOSHOCK BS 8436: Circuit Protection / 100m Reel White Sheath Type/Copper Size Cores VNS-S215EWT LSZH/Stranded 1.5 mm2 2 Core & CPC VNS-S225EWT LSZH/Stranded 2.5 mm2 2 Core & CPC VNS-S240EWT LSZH/Stranded 4.0 mm2 2 Core & CPC 3 core, 4 core and black sheathed available 500m reels available NOSHOCK® Circuit Protection Cables NKT INSTAL® PVC Twin & Earth Cables We connect a greener world NoBurn Plus: Fire Cable Enhanced 120 / 100m Reel Red Sheath White Sheath Size Cores VNP-215ERD VNP-215EWT 1.5 mm2 2 Core & CPC VNP-315ERD VNP-315EWT 1.5 mm2 3 Core & CPC VNP-415ERD VNP-415EWT 1.5 mm2 4 Core & CPC VNP-225ERD VNP-225EWT 2.5 mm2 2 Core & CPC 200m and 500m reels available NOBURN® Plus Fire Performance Cables BS 7629-1 Standard 120 BS 5839-1 26.2e Colour: Red, White, Black, Orange Contains a full 360ºC metal screen Provides additional protection for circuits installed at a depth of less than 50mm from surface to comply with requirements of BS7671 (522.6.204) Colour: White 2 and 3 core formats and conductor sizes 1–10mm2 with CPC. CPR Eca. BS 6004:2012+A1:2020 Supplied on sturdy cardboard reels Colour: Grey NKT INSTAL® Type 6242Y, 6243Y - PVC Product Code Type Size (Live/CPC) Cores VWY-210E10GRY 6242Y 1.0mm²/1.0mm² 2 Core & CPC VWY-215E10GRY 6242Y 1.5mm²/1.0mm² 2 Core & CPC VWY-225E15GRY 6242Y 2.5mm²1.5mm² 2 Core & CPC VWY-S240E15GRY 6242Y 4.0mm²/1.5mm² 2 Core & CPC VWY-S260E25GRY 6242Y 6.0mm²/2.5mm² 2 Core & CPC VWY-S2100ES40GRY 6242Y 10.0mm²/4.0mm² 2 Core & CPC 310E10GRY 6243Y 1.0mm²/1.0mm² 3 Core & CPC 315E10EGRY 6243Y 1.5mm²/1.0mm² 3 Core & CPC 50m reels available ventcroft.co.uk
7 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 FLEXIBLE CONDUIT * Also available in White **Also available in 10m and 50m reels Size mm Polypropylene Black Nylon PVC Galvanised Steel PVC Coated Galv. Steel 16 KNP16/100M KNY16/50M KNSP16/30M KMS16/30M KMPS16/30M 20 KNP20/100M* KNY20/50M KNSP20/30M KMS20/30M** KMPS20/30M** 25 KNP25/50M* KNY25/50M KNSP25/30M KMS25/30M** KMPS25/30M** 32 KNP32/50M KNY32/25M KNSP32/30M KMS32/30M KMPS32/30M GLANDS Size mm Hinged Polypropylene Nylon Compression for PVC Galv. Steel Fixed Galv. Steel Swivel 16 KNYG16/M16 KNSPG16/M16 KMG16/M20/F KMG16/M20/S 20 KNGH20/M20 KNYG20/M20 KNSPG20/M20 KMG20/M20/F KMG20/M20/S 25 KNGH25/M25 KNYG25/M25 KNSPG25/M25 KMG25/M25/F KMG25/M25/S 32 KNYG32/M32 KNSPG32/M32 KMG32/M32/F KMG32/M32/S IP40 IP66 IP65 IP40 or IP54 CONTRACTOR PACKS Size mm Polypropylene Nylon PA6 PVC Spiral PVC Coated Galv. Steel 20 KNP/20P*** KNY/20CP KNSP/20CP KMPS/20P 25 KNP/25P*** KNY/25CP KNSP/25CP ***Also available in White 10 metres of conduit | 10 glands | 10 locknuts IP66 IP66 IP65 IP54 www.koreflex.co.uk IP40 or IP54
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 8 The Marco Elite range is a striking series of perimeter trunking systems, designed to house high capacity power and data cabling. All trunking systems in the Elite range are CAT5, CAT6 and CAT6A compliant, and are able to house a number of cable configurations. Order Code Elite Profile ME3E Elite 3 MEC3E Elite Compact MT60E Elite 60 Order Code Elite Profile ME3T Elite 3 MEC3T Elite Compact MT60T Elite 60 Order Code Elite Profile ME3I Elite 3 MEC3I Elite Compact MT60I Elite 60 Order Code Elite Profile ME3F Elite 3 MEC3F Elite Compact MT60F Elite 60 Order Code Elite Profile ME3C Elite 3 MEC3C Elite Compact MT60C Elite 60 Order Code Description MTSB1 35mm MTSB1-4 35mm 4 lug MTSB1-25 25mm Order Code Elite Profile ME3J Elite 3 MEC3J Elite Compact MT60J Elite 60 Order Code Description MTSB2 35mm MTSB2-25 25mm MTSB2-50 50mm External Angle Flat Tee Internal Angle Flat Angle End Cover Joint Cover Socket Box 1-Gang Socket Box 2-Gang MARCO ELITE RANGE Order Code Profile Description ME3 Elite 3 175 x 60mm ME3LGL Elite 3 Light Grey lid ME3AM Elite 3 Anti-Microbial MEC3 Elite Compact 145 x 50mm MEC3LGL Compact Light Grey lid MEC3AM Compact Anti-Microbial MT60 Elite 60 200 x 63mm MEC3LGL Elite 60 Light Grey lid ME3 MEC3 MT60 Order Code Description MTBT Aluminium Bench Trunking Silver Finish MTBTW Aluminium Bench Trunking White Powder Coated MTBT-BB Back-to-Back Bench Trunking Silver Finish MTBT-BBW Back-to-Back Bench Trunking White Powder Coated MTBU1 Aluminium Bench Trunking Unit 1-Gang Silver Finish MTBU1W Aluminium Bench Trunking Unit 1-Gang White Powder Coated MTBU2 Aluminium Bench Trunking Unit 2-Gang Silver Finish MTBU2W Aluminium Bench Trunking Unit 2-Gang White Powder Coated Marco’s 3.6m power pole, and 650mm power post are both available in a satin anodised aluminium and white powder coated finishes. The systems benefit from a strong aluminium profile, designed to retain rigidity in all environments. Marco Bench Trunking and Bench Trunking Units, are manufactured from satin anodised aluminium and are fitted with a white uPVC lid and available in both satin anodised aluminium and white powder coated finishes. Marco’s bench trunking is also available as back to back lengths and units. 3.6m Power Pole 650mm Power Post MTP1/MTP1W MTPP1/MTPP1W Bench Trunking MTBT Back-to-back Bench Trunking MTBT-BB POWER POLES & POST BENCH TRUNKING www.atkore.com/marco
9 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 Part No. A-Code Description Pk Qty BT* 104066 100mm x 100mm PVC Bench Trunking c/w White Lid 3m BT-LGL* - 100mm x 100mm PVC Bench Trunking c/w Light Grey Centre Lid 3m * Only available to use with SLB1-A and SLB2-A Part No. A-Code Description Pk Qty 1 Gang Bench Box Single Sided / Double Sided BT-1G 104071 1 Gang Bench Box 1pc BT-1GD 104072 1 Gang Bench Box Double Sided 1pc 2 Gang Bench Box Single Sided / Double Sided BT-2G 104073 2 Gang Bench Box 1pc BT-2GD 104074 2 Gang Bench Box Double Sided 1pc 3 Gang Bench Box Single Sided / Double Sided BT1+2G 104075 3 Gang Bench Box 1pc BT1+2GD 104076 3 Gang Bench Box Double Sided 1pc Internal And External Angles BT-IB 104077 Internal Angle 1pc BT-EB 104078 External Angle 1pc Coupler BT/BC 104070 Coupler 1pc End Caps BT/BES 104068 End Cap 1pc BT/BED 104069 Double End Cap 1pc Divider MTW 50 19717 Divider 3m Adjustable Back Boxes 1G / 2G SLB1-A 104560 Single Adjustable Back Box 30mm-50mm 1pc SLB2-A 104561 Twin Adjustable Back Box 30mm-50mm 1pc NEW PP2WT POWER POLE Part No. A-Code Description Pk Qty PP2WT 105886 Power Pole 3.5m (Aluminum White) c/w 6x SLB1 1pc Key Design Features • New telescopic adjustable arm fixing for fast installation. • PP2WT (powder coated white) - 3.5m long, extendible up to 3.95m • More modern design • c/w 6 x 1 gang boxes (SLB1) including roof collar. • New design fixing for base • New design fixing for ceiling • Colours – Powder coated white (RAL9010). • Additional extra 2.5m extension kit (PP2EXT), enabling the power pole to be extended to a total of 6m Item Description 1 Adjustable Fixing Arm 100-400mm 2 Single Outlet Box 3 PVC Lid 4 Power Pole - 3.5m 5 Floor Fixing Plate 6 Ceiling Tile Collar BENCH TRUNKING & POWER POLES PVC BENCH TRUNKING www.dietzel-univolt.com
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 10 NEW STARLINE SLR 3 COMPARTMENT CURVED TRUNKING Univolt’s SLR 3 Compartment dado trunking is ideal for both power and data cabling, and designed to suit any application. At 170mm x 50mm, the new curved profile offers greater data capacity for the latest structured cabling, including Cat6/6a/Cat7 and Cat8. TRUNKING 50 x 170 Part No. A-Code Description Pk Qty SLR 50/170 101124 Dado Trunking Curved Profile 3m STARLINE TRUNKING Part No. A-Code Description Pk Qty SLC 50/170 82756 Dado Trunking Chamfered 3m SLQN 50/170 107281 Dado Trunking Square 3m SLSR 50/170 108522 Skirting Trunking 3m TRUNKING 50 x 170 Part No A-Code Description Pk Qty Internal Angle SRIE 50/170 108524 Internal Angle Skirting 1pc CIE 50/170 36066 Internal Angle Dado Chamfered 1pc QIEN 50/170 107287 Internal Angle Dado Square 1pc External Angles SRAE 50/170 108523 External Bend Skirting 1pc CAE 50/170 36067 External Bend Dado Chamfered 1pc QAEN 50/170 107288 External Angles Dado Square 1pc Flat Angles CFW 50/170 36729 Flat Angles Dado Chamfered 1pc QFWN 50/170 107285 Flat Angles Dado Square 1pc SRFWU 50/170 108525 Flat Bend Upward Skirting 1pc SRFWD 50/170 108526 Flat Bend Downward Skirting 1pc ACCESSORIES Adjustable Back Boxes 1G / 2G SLB1-A 104560 Single Adjustable Back Box 30mm-50mm 1pc SLB2-A 104561 Twin Adjustable Back Box 30mm-50mm 1pc Part No. A-Code Description Pk Qty Flat Angles SLRFA 50/170 108801 Flat Angle Dado Rounded * 1pc Flat Tees SLRFT 50/170 108802 Flat Tee Dado Rounded * 1pc Part No. A-Code Description Pk Qty SLR 50/170LG 105311 Dado Trunking Curved Profile c/w Light Grey Lid to meet DDA compliance 3m Part No. A-Code Description Pk Qty Internal Angle SLRIA 50/170 108799 Internal Angle Dado Rounded 1pc External Angles SLREA 50/170 108800 External Angle Rounded 1pc End Caps SLREC 50/170 101120 End Cap Dado Rounded 1pc Couplers SLRJC 50/170 101590 Coupler Dado Rounded 1pc ACCESSORIES ACCESSORIES Part No A-Code Description Pk Qty Flat Tees CFT 50/170 36783 Flat Tees Dado Chamfered 1pc QFTN 50/170 107284 Flat Tees Dado Square 1pc SRFTU 50/170 108528 Flat Tee Upward Skirting 1pc SRFTD 50/170 108529 Flat Tee Downward Skirting 1pc End Caps CE 50/170 36069 End Cap Dado Chamfered 1pc QE 50/170 36073 End Cap Dado Square 1pc SREL 50/170 108530 Left Hand End Cap Skirting 1pc SRER 50/170 108531 Right Hand End Cap Skirting 1pc Couplers SRK 50/170 108527 Coupler Skirting 1pc CK 50/170 36068 Coupler Dado Chamfered 1pc QKN 50/170 107289 Coupler Dado Square 1pc Back Boxes SLB1-A 104560 Single Adjustable Back Box 30–50mm 1pc SLB2-A 104561 Twin Adjustable Back Box 30–50mm 1pc SLB1 36075 Fixed single socket box – SLC only 1pc SLB2 36076 Fixed twin socket box – SLC only 1pc STARLINE SLR TRUNKING CAT6/6A/7/8 COMPATIBLE NEW NEW
11 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 Univolt’s Maxi Trunking is suitable for both power and structured cabling solutions. Our unique clip-on system gives a robust connection between the body and lid, making this an ideal trunking system for domestic, commercial and industrial applications MAXI TRUNKING Part No. A-Code Description Pk Qty MAK 50/50 36996 50/50 Maxi Trunking 12m MAK 50/75 19007 50/75 Maxi Trunking 12m MAK 50/100 36997 50/100 Maxi Trunking 12m MAK 50/150 22788 50/150 Maxi Trunking 6m MAK 75/75 19008 75/75 Maxi Trunking 12m MAK 75/100 19010 75/100 Maxi Trunking 6m MAK 75/150 22953 75/150 Maxi Trunking 6m MAK 100/100 19011 100/100 Maxi Trunking 6m MAK 100/150 22789 100/150 Maxi Trunking 3m MAK 150/150 22790 150/150 Maxi Trunking 3m TRUNKING Part No. A-Code Description Pk Qty External Angles MAE 50/50 19262 50 x 50 External Angle 1pc MAES 50/50 85634 50 x 50 External Angle 1pc MAE 50/75 19263 50 x 75 External Angle 1pc MAE 50/100 19264 50 x 100 External Angle 1pc MAES 50/100 86042 50 x 100 External Angle 1pc MAE 50/150 22962 50 x 150 External Angle 1pc MAE 75/75 19265 75 x 75 External Angle 1pc MAE 75/100 19266 75 x 100 External Angle 1pc MAE 75/150 22963 75 x 150 External Angle 1pc MAE 100/100 19267 100 x 100 External Angle 1pc MAE 100/150 22964 100 x 150 External Angle 1pc MAE 150/150 22965 150 x 150 External Angle 1pc Internal Angles MIE 50/50 19250 50 x 50 Internal Angles 1pc MIES 50/50 85632 50 x 50 Internal Angles 1pc MIE 50/75 19251 50 x 75 Internal Angles 1pc MIE 50/100 19252 50 x 100 Internal Angles 1pc MIES 50/100 86043 50 x 100 Internal Angles 1pc MIE 50/150 22958 50 x 150 Internal Angles 1pc MIE 75/75 19253 75 x 75 Internal Angles 1pc MIE 75/100 19254 75 x 100 Internal Angles 1pc MIE 75/150 22959 75 x 150 Internal Angles 1pc MIE 100/100 19255 100 x 100 Internal Angles 1pc MIE 100/150 22960 100 x 150 Internal Angles 1pc MIE 150/150 22961 150 x 150 Internal Angles 1pc ACCESSORIES Part No. A-Code Description Pk Qty Flat Angles MFW 50/50 19286 50 x 50 Flat Angle 1pc MFW 50/75 19287 50 x 75 Flat Angle 1pc MFW 50/100 19288 50 x 100 Flat Angle 1pc MFW 50/150 22966 50 x 150 Flat Angle 1pc MFW 75/75 19289 75 x 75 Flat Angle 1pc MFW 75/100 19290 75 x 100 Flat Angle 1pc MFW 75/150 22967 75 x 150 Flat Angle 1pc MFW 100/100 19291 100 x 100 Flat Angle 1pc MFW 100/150 22968 100 x 150 Flat Angle 1pc MFW150/150 22969 150 x 150 Flat Angle 1pc FLAT TEE MFT 50/50 19274 50 x 50 Flat Tee 1pc MFT 50/75 19275 50 x 75 Flat Tee 1pc MFT 50/100 19276 50 x 100 Flat Tee 1pc MFT 50/150 22970 50 x 150 Flat Tee 1pc MFT 75/75 19277 75 x 75 Flat Tee 1pc MFT 75/100 19278 75 x 100 Flat Tee 1pc MFT 75/150 22971 75 x 150 Flat Tee 1pc MFT 100/100 19279 100 x 100 Flat Tee 1pc MFT 100/150 22972 100 x 150 Flat Tee 1pc MFT 150/150 22973 150 x 150 Flat Tee 1pc Trunking Divider MTW 50 19717 50mm Trunking Divider 3m MTW 75 19718 75mm Trunking Divider 3m MTW 100 19719 100mm Trunking Divider 3m Single And Twin Socket MIB60/100 Single-2 23230 Single Socket Box 80x100x28mm - 2 Lugs 1pc MIB60/100 Single-4 23230 Single Socket Box 80x100x28mm - 4 Lugs 1pc MIB120/100 Twin 23232 Twin Socket Box 140x100x28mm 1pc MIB60/150 Single 23231 Single Socket Box 80x150x28mm 1pc MIB120/150 Twin 23233 Twin Socket Box 140x150x28mm 1pc Stop End ME 50/50 19308 50x50 Stop End 1pc ME 50/75 19309 50x75 Stop End 1pc ME 50/100 19310 50x100 Stop End 1pc ME 50/150 22163 50x150 Stop End 1pc ME 75/75 19311 75x75 Stop End 1pc ME 75/100 19312 75x100 Stop End 1pc ME 75/150 22165 75x150 Stop End 1pc ME 100/100 19313 100x100 Stop End 1pc ME 100/150 22167 100x150 Stop End 1pc ME 150/150 22169 150x150 Stop End 1pc MAK50/100 can be installed as a dado trunking for both power and data cables. MAK50/100 is compatible with MIB60/100 Single Backbox and MIB120/100 Twin Backbox.
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 12 BLADE TERMINAL COPPER Finish: Tin Plated Voltage: 600V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 27A Red - 19A Yellow - 24A Code Type TBB18 Blue 18.4mm TBR18 Red 18.4mm TBY10 Yellow 10.0mm FLAG FEMALE PUSH-ON TERMINAL BRASS Finish: Brass, Tin Plated Voltage: 300V @ 75°C Insulated: Nylon Electric Rating: Blue - 15A Red - 10A Code Type TPFFR Red 0.5 - 1.5 TPFFB Blue 1.5 - 2.5 PRE-INSULATED CRIMP TERMINALS Conform to BS4579 & BS4G178 RING TERMINAL COPPER Finish: Tin Plated Voltage: 600V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 27A Red - 19A Yellow - 24A Code Type TRB32 Blue 3.2 TRB37 Blue 3.7 TRB43 Blue 4.3 TRB53 Blue 5.3 TRB64 Blue 6.4 TRB8 Blue 8.4 TRB10 Blue 10.5 TRR32 Red 3.2 TRR37 Red 3.7 TRR43 Red 4.3 Code Type TRR53 Red 5.3 TRR64 Red 6.4 TRR85 Red 8.4 TRR10 Red 10.5 TRY43 Yellow 4.3 TRY53 Yellow 5.3 TRY64 Yellow 6.4 TRY8 Yellow 8.4 TRY10 Yellow 10.5 TRY12 Yellow 13.0 FORK TERMINAL COPPER Finish: Tin Plated Voltage: 600V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 27A Red - 19A Yellow - 48A Code Type TFB32 Blue 3.2 TFB37 Blue 3.7 TFB43 Blue 4.3 TFB53 Blue 5.3 TFB64 Blue 6.4 TFR32 Red 3.2 TFR37 Red 3.7 Code Type TFR43 Red 4.3 TFR53 Red 5.3 TFR64 Red 6.4 TFY37 Yellow 3.7 TFY43 Yellow 4.3 TFY53 Yellow 5.3 TFY64 Yellow 6.4 FULLY INSULATED FEMALE PUSH-ON TERMINAL BRASS Finish: Tin Plated Voltage: 300V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 15A Red - 10A Yellow - 24A Code Type TPFB48FI Blue 4.8 TPFB63FI Blue 6.3 TPFR28FI Red 2.8 TPFR48FI Red 4.8 TPFR63FI Red 6.3 TPFY63FI Yellow 6.3 TPFY95FI Yellow 9.5 PIGGY-BACK PUSH-ON TERMINAL COPPER Finish: Copper, Tin Plated Voltage: 300V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 15A Red - 10A Yellow - 24A Code Type TPPB Red 6.3 TPPR Blue 6.3 TPPY Yellow 6.3 MALE PUSH-ON TERMINAL BRASS Finish: Tin Plated Voltage: 300V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 15A Red - 10A Yellow - 24A Code Type TPMB48 Blue 4.8 TPMB Blue 6.3 TMPR28 Red 2.8 Code Type TPMR48 Red 4.8 TPMR Red 6.3 TPMY Yellow 6.3 SPLICE/BUTT TERMINAL COPPER Material: Copper, Tin Plated Voltage: 600V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 27A Red - 19A Yellow - 48A Code Type TSB Blue TSR Red TSY Yellow HEAT SHRINK BUTT SPLICE CONNECTOR COPPER Finish: Copper, Tin Plated Voltage: 600V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 27A Red - 19A Yellow - 48A Code Type THSB Blue THSR Red THSY Yellow PIN TERMINAL COPPER Finish: Tin Plated Voltage: 600V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 27A Red - 19A Yellow - 24A Code Type TPB12 Blue 12.0mm TPR12 Red 12.0mm TPY14 Yellow 14.0mm FEMALE PUSH-ON TERMINAL BRASS Finish: Tin Plated Voltage: 300V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 15A Red - 10A Yellow - 24A Code Type TPFB Blue 6.3 TPFB48 Blue 4.8 TPFR Red 6.3 TPFR28 Red 2.8 Code Type TPFR48 Red 4.8 TPFY Yellow 6.3 TPFY95 Yellow 9.5 BULLET TERMINAL BRASS Finish: Copper, Tin Plated Voltage: 300V @ 75°C Insulated: Polyvinyl Chloride Electric Rating: Blue - 19A Red - 27A Yellow - 48A Code Type TBFB Female Blue 5mm TBFR Female Red 4mm TBFY Female Yellow 5mm TBMB Male Blue 5mm TBMR Male Red 4mm TBMY Male Yellow 5mm www.deligo.co.uk
13 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 COPPER LUG BELLED ENTRY Material: Copper, Tin Plated Usage: Suitable for Power Cables up to 100V BUTT SPLICE COPPER Material: Copper, Tin Plated Usage: Suitable for Power Cables up to 100V Belled entry for ease of use Code Size CB6 6mm2 CB10 10mm2 CB16 16mm2 CB25 25mm2 CB35 35mm2 CB50 50mm2 CB70 70mm2 Code Size CB95 95mm2 CB120 120mm2 CB150 150mm2 CB185 185mm2 CB240 240mm2 CB300 300mm2 CB400 400mm2 Belled entry for ease of use Standard: BS 7609 Packed in 10s (Larger sizes can be split) Code Type CL65 6mm2 5mm Fix CL66 6mm2 6mm Fix CL68 6mm2 8mm Fix CL610 6mm2 10mm Fix CL105 10mm2 5mm Fix CL106 10mm2 6mm Fix CL108 10mm2 8mm Fix CL1010 10mm2 10mm Fix CL1012 10mm2 12mm Fix CL165 16mm2 5mm Fix CL166 16mm2 6mm Fix CL168 16mm2 8mm Fix CL1610 16mm2 10mm Fix CL1612 16mm2 12mm Fix CL255 25mm2 5mm Fix CL256 25mm2 6mm Fix CL258 25mm2 8mm Fix CL2510 25mm2 10mm Fix Code Type CL15020 150mm2 20mm Fix CL18510 185mm2 10mm Fix CL18512 185mm2 12mm Fix CL18514 185mm2 14mm Fix CL18516 185mm2 16mm Fix CL18520 185mm2 20mm Fix CL24010 240mm2 10mm Fix CL24012 240mm2 12mm Fix CL24014 240mm2 14mm Fix CL24016 240mm2 16mm Fix CL24020 240mm2 20mm Fix CL30010 300mm2 10mm Fix CL30012 300mm2 12mm Fix CL30016 300mm2 16mm Fix CL40010 400mm2 10mm Fix CL40012 400mm2 12mm Fix CL40016 400mm2 16mm Fix CL40020 400mm2 20mm Fix Code Type CL7016 70mm2 16mm Fix CL7020 70mm2 20mm Fix CL958 95mm2 8mm Fix CL9510 95mm2 10mm Fix CL9512 95mm2 12mm Fix CL9514 95mm2 14mm Fix CL9516 95mm2 16mm Fix CL1208 120mm2 8mm Fix CL12010 120mm2 10mm Fix CL12012 120mm2 12mm Fix CL12014 120mm2 14mm Fix CL12016 120mm2 16mm Fix CL12020 120mm2 20mm Fix CL1508 150mm2 8mm Fix CL15010 150mm2 10mm Fix CL15012 150mm2 12mm Fix CL15014 150mm2 14mm Fix CL15016 150mm2 16mm Fix Code Type CL2512 25mm2 12mm Fix CL355 35mm2 5mm Fix CL356 35mm2 6mm Fix CL358 35mm2 8mm Fix CL3510 35mm2 10mm Fix CL3512 35mm2 12mm Fix CL3514 35mm2 14mm Fix CL506 50mm2 6mm Fix CL508 50mm2 8mm Fix CL5010 50mm2 10mm Fix CL5012 50mm2 12mm Fix CL5014 50mm2 14mm Fix CL5015 50mm2 15mm Fix CL706 70mm2 6mm Fix CL708 70mm2 8mm Fix CL7010 70mm2 10mm Fix CL7012 70mm2 12mm Fix CL7014 70mm2 14mm Fix CORD ENDS (DOUBLE) Material: Copper, Tin Plated Usage: Suitable for Power Cables up to 100V Belled entry for ease of use Code Size Pack Qty CED0.5 0.52 mm 100 CED0.75 0.752 mm 100 CED1.0 1.02 mm 100 CED1.5 1.52 mm 100 CED2.5 2.52 mm 100 CED4.0 4.02 mm 100 CED6.0 6.02 mm 100 CED10.0 10.02 mm 100 CED16.0 16.02 mm 100 CRIMPING TOOL KIT/TERMINAL INSTALLATION KIT INTERCHANGEABLE Code Type CTK Ratchet Crimping Tool Set (Comes with 5 dies) DIES Die set for pin terminal/insulated or non/insulated ferrules (cord ends) DL-5D2 Crimp dimension AWG 6 /4 /2 & DIN 16 /25 /35mm2 DL-2E2 Crimp dimension AWG 22/20 /18 /16 /14 /12 /10 /8 /6 & DIN 0.5 / 0.75 /1.0 /1.5 /2.5 /4 /6 /10 /16mm2 Die set for non insulated terminals and copper lugs/ butt splices. DL-2N Crimp dimension AWG 20–18 /16–14 /12–10 /8 & DIN 1.5/2.5 /6 / 10mm2 DL-5N1 Crimp dimension AWG 8 / 6 / 4 & DIN 10 / 16 / 25mm2 Die set for insulated terminals DL-2H Crimp dimension AWG 22-18 / 16- 14 / 12-10 & DIN 0.5-1 / 1.5-2.5 / 4-6mm2 •Full Cycle Ratchet crimper with 5 interchangeable die sets for insulated, non-insulated ferrule, cord-end, copper lugs and butt splice terminals. •Removable thumb screws for quick change of dies. •Built in safety ratchet mechanism provides precise crimping. •Angled head with streamlined ergonomic grips enhances operation effectively & comfortably. •High leverage design structure of frame provides easy crimp action. •5 Tools in one! ASSORTED CORD ENDS/BOOTLACE FERRULES (FRENCH & GERMAN) Contains: 8 Popular Sizes 0.52mm x 10.02mm Code Size CEK2 Cord Ends (French) CEK1 Cord Ends (German) CORD ENDS (FRENCH) Standard: DIN 46228-4 Suitable: For tri-rated cable Code Size Pack Qty CE0.25F 0.252 mm x 6.5mm 100 CE0.5F 0.52 mm x 8.0mm 100 CE0.75F 0.752 mm x 8mm 100 CE1.0F 1.02 mm x 8mm 100 CE1.5F 1.52 mm x 8mm 100 CE2.5F 2.52 mm x 8mm 100 CE4.0F 4.02 mm x 9mm 100 CE6.0F 6.02 mm x 12mm 100 CE10.0F 10.02 mm x 12mm 100 CE16.0F 16.02 mm x 12mm 100 CE25.0F 25.02 mm x 16mm 100 CE35.0F 35.02 mm x 16mm 100 JELLY CRIMPS 8A 2 & 3 WAY Code Type Pack Qty JC2 8A 2 Way 100 JC3 8A 3 Way 100 PRE-INSULATED CRIMP TERMINALS CORD ENDS (GERMAN) Standard: DIN 46228-4 Suitable: For tri-rated cable Code Size Pack Qty CE0.25G 0.252 mm x 6.5mm 100 CE0.5G 0.52 mm x 8.0mm 100 CE0.75G 0.752 mm x 8mm 100 CE1.0G 1.02 mm x 8mm 100 CE1.5G 1.52 mm x 8mm 100 CE2.5G 2.52 mm x 8mm 100 CE4.0G 4.02 mm x 9mm 100 CE6.0G 6.02 mm x 12mm 100 CE10.0G 10.02 mm x 12mm 100 CE16.0G 16.02 mm x 12mm 100 CE25.0G 25.02 mm x 16mm 100 CE35.0G 35.02 mm x 16mm 100 Conform to BS4579 & BS4G178
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 14 INTRODUCING IDEAL ELECTRICAL IDEAL Electrical has been operating in the UK since 1992 and supplies electrical wholesalers and distributors with innovative solutions to meet their customer’s requirements while committing to IDEAL’s core values: strength in relationships and transparency in business. Our goal is to help you deliver improved installation speed, quality and value for your customers. You can trust us to offer best in class products across a wide selection of electrical consumables, tools and equipment, all of which have been thoroughly tested and proven. Over the next couple of pages you’ll find a selection of our products, but if you are looking for more, do not hesitate to visit our website idealind.com. Alternatively, ask your AIEW wholesaler for more details. PUSH-IN & LEVER WIRE CONNECTORS www.idealind.com 32 AMP The SpliceLine® in-line wire connector provides a crimp free, solderless butt splice. The two port model accepts up to 4.0mm2 cable, allowing one connector to do the job of multiple through crimps. Its end-to-end connection is also a great solution for pre-fab operations. • Easy way of extending wire that has been cut short • Tool free, push-in through crimp • Window for visual inspection of connection • UKCA, CE and 18th Edition compliant Code Description 30-1042 SpliceLine connectors (100) Kits including SpliceLine wire connectors 30-5011EU 120 pcs kit including 30 pcs 30-5025EU 80 pcs kit including 15 pcs 30-5026EU 240 pcs including 30 pcs Enclosure Box for use with Ideal Connectors 30-4000 Enclosure Box (10) SPLICELINE® IN-LINE CONNECTORS PUSH-IN CONNECTORS Code Description 30-1032 2-port push-in wire connectors 100 pcs 30-1033 3-port push-in wire connectors 100 pcs 30-1034 4-port push-in wire connectors 100 pcs 30-0087 5-port push-in wire connectors 50 pcs 30-0088 6-port push-in wire connectors 50 pcs 30-0090 8-port push-in wire connectors 50 pcs 30-1039EU 3-port 6mm push-in wire connectors 30 pcs The push-in wire connector can reduce installation time by up to 50% compared to more traditional connection methods such as terminal blocks. They are the perfect replacement for crimped splices. • All connectors are rated to 32A and the 6 mm push-in is rated up to 41A • Suitable for wire sizes of 0.75mm2 – 4mm2 • UKCA, CE and 18th Edition compliant 32 AMP GEN II LEVER CONNECTORS The IDEAL Gen II lever connectors offer a fast, simple and cost-effective alternative to terminal strips allowing electrical professionals to save time and money on site while achieving easier, more consistent terminations for wires up to 4mm2 and 32A. • For use in applications including lighting, HVAC, access control, radial and final ring circuits • Suitable for wire sizes of 0.14mm2 to 4mm2 • Levers open in the opposite direction of insertion points to avoid accidental loosening/pull out • UKCA, CE and 18th Edition compliant Code Description 30-0092 2-port Gen II lever wire connectors 40 pcs 30-0093 3-port Gen II lever wire connectors 40 pcs 30-0095 5-port Gen II lever wire connectors 30 pcs 30-0099 Mixed Gen II lever wire connectors 30 pcs 30-5025EU Mixed Gen II lever/push-in-80 pcs 30-5026EU Mixed Gen II lever/push-in-240 pcs 30-5002EU T&E Kit with tools and 100 connectors 32 AMP COMPLETE CATALOGUE WIRE CONNECTOR SOLUTIONS
15 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 WIRE CONNECTOR KITS Code Description 44-985UK Contractor Lockout/Tagout Kit 44-995 Contractor PRO Lockout/Tagout Kit 44-924 Domestic Installer Lockout/Tagout Kit 44-925 Personal Lockout/Tagout Kit IDEAL offers a range of wire connector kits comprising of Push-In, SpliceLine® and/or Gen II Lever wire connectors meeting the needs of today’s modern electricians who demand quality products that satisfy the requirement to make safe and reliable connections of wires in a variety of wiring applications. • 32A Push-In Connector Installer Kit (120 pcs) • Push-In Connector Premium Kit (255 pcs) • Push-In Connector Starter Kit (110 pcs) • Push-In & Gen II Lever Wire Connector Kit (80 pcs) • Push-In & Gen II Lever Premium Kit (240 pcs) • T&E kit including 100 Lever/Push-In connectors plus Data T®-Cutter (45-074) and T&E Stripper (45-235) Code Description 30-5011EU 32A Installer kit 120 pcs 30-5020EU Push-In Premium kit 255pcs 30-5021EU Push-In Starter kit 110pcs 30-5025EU Mixed Gen II lever/push-in 80 pcs 30-5026EU Mixed Gen II lever/push-in 240 pcs 30-5002EU T&E Kit with tools and 100 connectors IDEAL offers a range of lockout/tagout products to provide a cost-effective and safe solution in the management of electrical safety and circuit isolation in the workplace. IDEAL lockout/tagout devices help to achieve compliance with current regulations. INSTALLATION Code Description 31-358 Yellow 77 - 0.95 l. squeeze bottle 31-388 ClearGlide - 0.95 l. squeeze bottle 31-378 AquaGel II - 0.95 l. squeeze bottle 38-500 IDEAL Wipes - 82 pcs. 31-055 60ft (18 m) Blued-steel fish tape 31-056 120ft (36 m) Blued-steel fish tape All IDEAL lubricants are pH neutral, environmentally safe, non-toxic, non-flammable and non-corrosive with great temperature ranges and low co-efficient of friction. • Y77 - wax based drying to a thin, non-conductive film, clings to cable even where moisture is present • ClearGlide - polymer based, safe for all cable types, clear and colourless for quick and easy clean up • AquaGel II - polymer based for outdoor use only FT-45™ FEED-THRU TOOL & KITS Code Description 30-495 FT-45TM Feed-Thru Modular Plug Crimp Tool 30-5014EU Unshielded Kit 30-5015EU Premium Kit 30-5016EU Smart Home Kit The FT-45TM is a simple, compact and highly effective crimp tool for installers and technicians that terminate RJ45 connectors regularly. Suitable with Feed-Thru, standard, or shielded connectors, Cat 5e, 6 or 6A. • Speed - The simplified process of RJ45 data terminations increases productivity • Accuracy - Cleanly shears the excess conductors and leaves a smooth, flat finish • Reliability - Clear connector design for visual inspection of wiring order reducing errors MODULAR PLUGS FOR FT-45™ TOOL Code Description 85-370 CAT5e FT RJ45 unshielded 25 pcs 85-371 CAT5e FT RJ45 unshielded 50 pcs 85-372 CAT5e FT RJ45 unshielded 100 pcs 85-375 CAT6 FT RJ45 unshielded 25 pcs 85-376 CAT6 FT RJ45 unshielded 50 pcs 85-377 CAT6 FT RJ45 unshielded 100 pcs 85-365 CAT5e FT shielded RJ45 25 pcs 85-369 CAT6A/6/5e Shielded Feed-Thru 50 pcs 85-368 CAT6A/6/5e Shielded Feed-Thru 25 pcs Open end Feed-Thru (FT) connectors offer several advantages over standard closed end connectors. • Reduces errors - Wires can be easily verified before trimming • Easy to use - Conductors do not need to be pretrimmed to a specific length • Improved wire stability – 3 prong contacts into every wire for more conductive contact points MODULAR PLUG SOLUTIONS, TEST EQUIPMENT & MORE TEST & MEASUREMENT Code Description 61-946 SureTrace Circuit Tracer 0-480 Vac/dc 61-757 600A A ac/dc Clamp Meter 61-747 400A ac/dc Clamp Meter TightSightTM 61-637 24-600Vac Non-Contact Voltage Tester 61-657 12-1000V Non-Contact Voltage Tester 33-864 Pro Tone Generator & Amplifier Probe Kit 33-856 VDV Multimedia Wiremapper & Tester 62-200 LinkMasterTM Wiremapper The IDEAL T&M range includes Circuit Tracers, Clamp Meters, Split Jaw Meters, Multimeters, Voltage Testers, Non-Contact Voltage Testers and Infrared Thermometers with a range of features designed to enhance productivity and safety. The IDEAL Data test range includes amplifier probe, LinkMasterTM and VDV Cable Tester as individual part numbers or in a variety of kits. SCAN HERE FOR LOTO SECTION LOCKOUT/TAGOUT SAFETY KITS SCAN HERE FOR FT-45 VIDEO SCAN HERE FOR COMPLETE DATA SECTION T&M CATALOGUE DATA TEST CATALOGUE WIRE PULLING SUPPLIES
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 16 POWERTRACK A range of 63Amp CE (clean earth) and standard powertrack complete with integral mounting brackets and pre-assembled end caps and couplers for ease of installation. Standard Clean Earth (CE) Length No. of Outlets Pitch (mm) Pack UN1112 UN1212 1.2m 4 300 2 UN1118 UN1218 1.8m 6 300 2 UN1114 UN1214 2.4m 8 300 2 UN1116 UN1216 3.6m 12 300 2 UN11112 UN1212 TUFFLEX TILE The Tufflex Tile is a quick and easy pattress solution that takes the hassle out of traditional ceiling installations. A cleaner, lighter, safer and faster alternative to wood solutions, the Tufflex Tile is super lightweight, strong and easy to cut or drill meaning installations can be completed far more quickly. Additionally, the product is flame retardant and LSF removing a key component of the fire triangle. Code Dimensions Pack CPT1 595 x 595 x 4mm 25 Code Dimensions (mm) Pack MT2/7389 60 x 65 2 x 3m MT2/7248 100 x 65 2 x 3m MT2/7249 150 x 65 2 x 3m MT2/7250 200 x 65 2 x 3m MT2/7251 300 x 65 2 x 3m MT2/7394 400 x 65 2 x 3m MT2/7395 500 x 65 2 x 3m MT2/7396 600 x 65 2 x 3m WIRE BASKET A range of Fast Coupling Wire Basket for the simple routing of power and data cables. Strong and simple to install, Basor Wire Basket offers maximum cable ventilation and a high level of resistance to cable movement. Connection between sections of wire basket is quick and easy thanks to the integral couplers which results in reduced installation times and labour savings. A unique rippled wire design enhances the product strength and resists flexing. Fast Coupling Wire Basket 65mm Height FLOOR BOXES A high quality range of raised floor boxes to provide power and data to desks within the modern office environment. Boxes are supplied with dividers for quick and easy configuration as either a 3 or 4 compartment box. Standard CE Description Dimensions Pack UPW400 UPW405 1 x 2 gang 357 x 257 x 83mm 1 UPW420 UPW425 2 x 2 gang 357 x 257 x 83mm 1 Code Description Pack UM1000 Empty Floor box - Plastic lid & trim 1 UM1500 Empty Floor box - Steel lid & trim 1 UM3010 Floor Box pre-fitted with 3 x UP632 plates 1 Standard CE Description Dimensions Pack UPW410 UPW415 1 x 2 gang standard 357 x 257 x 83mm 1 UPW430 UPW435 2 x 2 gang standard 357 x 257 x 83mm 1 3 Compartment Pre-Wired Box with 3m Tap-off 4 Compartment Pre-Wired Box with 3m Tap-off www.marshall-tufflex.com
17 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 ODYSSEY BIO Odyssey BIO is a threecompartment trunking with a completely curved front profile designed with tamper resistant covers and flush accessories. The trunking is manufactured with antimicrobial BIO properties inherent to the PVC-U and has an easy to clean profile making it ideal for healthcare environments. Code Description Pack DD1WH Odyssey trunking assembly – 180 x 57mm 1 x 3m DD1210WH Coupler 1 DD1230WH End cap 2 DD1310WH Internal bend 1 DD1350WH External bend 1 DD1330WH Internal bend adjustable 1 DD1370WH External bend adjustable 1 EIBAB20WH Internal bend adjustable 85º–95º 1 EXBAB20WH External bend adjustable 85º–95º 1 DD1410WH Flat angle 1 DD1430WH Flat tee 1 DD1720WH 20mm Conduit adaptor 1 Code Description Pack EPM20WH Sterling Compact Trunking Assembly 1 x 3m EMT20WH Trunking Base inc 2 Angled Outer Covers 4 x 3m ETL1WH Main Compartment Cover 8 x 3m EC20WH Coupler 2 EEC20WH End Cap 2 EIB20WH Internal Bend 2 EXB20WH External Bend 2 EIBAB20WH Internal bend adjustable 85º–95º 2 EXBAB20WH External bend adjustable 85º–95º 2 EFA20MWH Flat Angle - Up/Down 1 EFT20MWH Flat Tee - Up/Down 1 STERLING COMPACT Sterling Compact is an economical and stylish threecompartment trunking, at 140 x 50mm it is designed to fit within areas that may have trunking height restrictions. Manufactured using 54% recycled material. PP685WHWH PP36001WHWH STERLING CURVE Sterling Curve is a sleek data compliant medium sized trunking system with three segregated compartments. The adaptable system has 1 or 2 curved data compartments designed to stop clutter, avoid dust traps and to make cleaning easy. Manufactured using 55% recycled material (Dado) and 52% recycled material (Skirting). Code Trunking assembly 167 x 50mm Pack Qty CEP1MWH Curve Dado– Curved top/bottom 1 x 3m CEP2MWH Curve Skirting – Curved top/square bottom 1 x 3m CEP1MWH CEP2MWH Code Description Pack CECP1MWH Curve Dado Coupler 2 CECP2MWH Curve Skirting Coupler 2 CEECP1MWH Curve Dado End cap 2 CEECP2MRHWH Curve Skirting End cap right hand 2 CEECP2MLHWH Curve Skirting End cap left hand 2 CEIBP1MWH Curve Dado Internal bend 2 CEXBP1MWH Curve Dado External bend 2 CEIBP1ABWH Curve Dado Internal bend adjustable 85º–95º 2 CEXBP1ABWH Curve Dado External bend adjustable 85º–95º 2 CEIBP2MWH Curve Skirting Internal bend 2 CEXBP2MWH Curve Skirting External bend 2 CEFA1MBWH Curve Dado Flat angle 1 CEFA2UMBWH Curve Skirting Flat angle up 1 CEFT1MBWH Curve Dado Flat tee 1 CEFT2MBWH Curve Skirting Flat tee 1 PowerPoles and Posts are a practical solution for the management of power, data and communication services to island workstations. POWERPOLES AND POWERPOSTS Code Description Finish PP36001ANWH POWERPOLE Double sided square Anodised body / white fittings PP36001WHWH POWERPOLE Double sided square White body / white fittings PP685ANWH POWERPOST Double sided square Anodised body / white fittings PP685WHWH POWERPOST Double sided square White body / white fittings • Aluminium body for strength & rigidity with PVC-U covers • Supplied with 6 accessory plates • Maximum pole height is 3686mm (250mm adjustable slide) • Overall height of PowerPost is 692mm (inc. cap) • Pack Quantity : 1
A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 18 • Meets mechanical strength of BS6946:1988 • Each length marked in line with the British Standards, with additional batch number added for full traceability • Compliant to BSEN10346 with each length receiving a pre-galvanised Z275 finish • 5 year extended warranty available when used as part of a complete system. Full information available on request. • Light gauge options are also available Code Description MPC1/3 41 x 41 x 2.5mm Steel Channel: Plain / 3m MPC2/3 41 x 41 x 2.5mm Steel Channel: Slotted / 3m (28 x 14mm slots) MPC6/3 41 x 21 x 2.5mm Steel Channel: Plain / 3m MPC7/3 41 x 21 x 2.5mm Steel Channel: Slotted / 3m (28 x 14mm slots) MPC1/6 41 x 41 x 2.5mm Steel Channel: Plain / 6m MPC2/6 41 x 41 x 2.5mm Steel Channel: Slotted / 6m (28 x 14mm slots) MPC6/6 41 x 21 x 2.5mm Steel Channel: Plain / 6m MPC7/6 41 x 21 x 2.5mm Steel Channel: Slotted / 6m (28 x 14mm slots) STEEL CHANNEL www.metpro.co.uk Code Description GC20 20mm x 3.75m Class 4 Hot Dip Galvanised Steel Conduit Tube GC25 25mm x 3.75m Class 4 Hot Dip Galvanised Steel Conduit Tube GC20/3 20mm x 3m Class 4 Hot Dip Galvanised Steel Conduit Tube GC25/3 25mm x 3m Class 4 Hot Dip Galvanised Steel Conduit Tube GCP20 20mm x 3.75m Pre-Galvanised Steel Conduit Tube GCP25 25mm x 3.75m Pre-Galvanised Steel Conduit Tube GCP20/3 20mm x 3m Pre-Galvanised Steel Conduit Tube GCP25/3 25mm x 3m Pre-Galvanised Steel Conduit Tube MALLEABLE BOXES Code Description MB1G 20mm Terminal Box MB2G 20mm Through Box MB3G 20mm Angle Box MB4G 20mm Tee Box MB5G 20mm Intersection Box MB6G 20mm Branch U Box MB7G 20mm Branch Y Box CONDUIT TUBE • Each length features a consistent 60º angle thread, a requirement to meet DIN976. Metpro® threaded rod connectors are also manufactured with 60º threads in line with DIN6334 • Manufactured from 4.8 grade steel, ensuring the required mechanical strength of the market • Consistent 60º threads mean more material, resulting in a stronger, more reliable product • 5 year extended warranty available when used as part of a complete system. Full information available on request. • Fully RoHS2 Compliant Code Description TR6 M6 x 3m Thread Rod TR8 M8 x 3m Thread Rod TR10 M10 x 3m Thread Rod TR12 M12 x 3m Thread Rod TRC6 M6 Threaded Rod Connector TRC8 M8 Threaded Rod Connector TRC10 M10 Threaded Rod Connector TRC12 M12 Threaded Rod Connector METPRO® THREADED ROD AND CONNECTORS Code Description FCCP20 20mm PVC Contractor Pack FCCP25 25mm PVC Contractor Pack • IP40 Rated • Consists: 1x 10m coil PVC flexible conduit, 10x 20mm PVC swivel adaptors • Temperature Range: -15oC to +60oC • Compression Class: 2 (320N) • Manufactured from self-extinguishing PVC CONTRACTOR PACKS Code Description MB8G 25mm Terminal Box MB9G 25mm Through Box MB10G 25mm Angle Box MB11G 25mm Tee Box MB12G 25mm Intersection Box MB13G 25mm Branch U Box MB14G 25mm Branch Y Box
19 A I EW Membe r P roduc t Cata l ogue Ed i t i on 24 LOCKNUTS Code Description LN16G 16mm Locknut LN1G 20mm Locknut LN2G 25mm Locknut LN3G 32mm Locknut LN4G 1.5” Locknut LN40G 40mm Locknut LN5G 2” Locknut Code Description MBBS1 20mm Short Male Brass Bush MBBS2 25mm Short Male Brass Bush MBBS3 32mm Short Male Brass Bush MBBS4 1.5” Short Male Brass Bush MBBS5 2” Short Male Brass Bush MBBS16 16mm Short Male Brass Bush MALE BRASS BUSHES Long Code Description MBBL1 20mm Long Male Brass Bush MBBL2 25mm Long Male Brass Bush MBBL3 32mm Long Male Brass Bush MBBL4 1.5” Long Male Brass Bush MBBL5 2” Long Male Brass Bush MBBL6 63mm Long Male Brass Bush MBBL7 2.5” Long Male Brass Bush MBBL8 75mm Long Male Brass Bush MBBL9 3” Long Male Brass Bush FEMALE BRASS BUSHES Code Description FBB1 20mm Female Brass Bush FBB2 25mm Female Brass Bush FBB3 32mm Female Brass Bush FBB4 1.5” Female Brass Bush FBB5 2” Female Brass Bush FBB6 63mm Female Brass Bush FBB7 2.5” Female Brass Bush FBB8 75mm Female Brass Bush FBB9 3” Female Brass Bush SOLID COUPLERS Code Description SC1 20mm Solid Coupler SC2 25mm Solid Coupler BOX LID SCREWS Code Description BM6 M4 x 6mm Brass Box Lid Screw BM10 M4 x 10mm Brass Box Lid Screw BM12 M4 x 12mm Brass Box Lid Screw BM16 M4 x 16mm Brass Box Lid Screw BM20 M4 x 20mm Brass Box Lid Screw BM25 M4 x 25mm Brass Box Lid Screw BM30 M4 x 30mm Brass Box Lid Screw BM35 M4 x 35mm Brass Box Lid Screw BM40 M4 x 40mm Brass Box Lid Screw BM50 M4 x 50mm Brass Box Lid Screw Steel LR16 16mm Lock Ring LR1 20mm Lock Ring LR2 25mm Lock Ring LR3 32mm Lock Ring LR4 1.5” Lock Ring LR5 2” Lock Ring LOCK RINGS Code Description Brass LR6 63mm Brass Lock Ring LR7 2.5” Brass Lock Ring LR8 75mm Brass Lock Ring LR9 3” Brass Lock Ring FLUSH BACK BOXES Code Description EWS1 16mm 1 Gang Flush Box EWS2 25mm 1 Gang Flush Box EWS3 25mm 2 Gang Flush Box EWS4 35mm 1 Gang Flush Box (20mm and 25mm Knockouts) EWS5 35mm 2 Gang Flush Box EWS6 35mm Dual Flush Box EWS6/25 25mm Dual Flush Box EWS7 47mm 1 Gang Flush Box EWS8 47mm 2 Gang Flush Box EWS1 EWS4 EWS6/25 EWS8 32mm, 63mm, 75mm, 1.5" and 2" sizes also available. www.metpro.co.uk Short
